PortaSpec® XLE

Light Element Analysis

in Central Lab

Portaspec WDXRF Analysis Spectrometry - Cianflone.com

Product Overview

PortaSpec® XLE is designed to fill a need for an instrumental technique that could rapidly and non-destructively analyze light elements in a central laboratory or in the plant using wavelength dispersive x-ray (WDXR) fluorescence. The PortaSpec® XLE has the ability to analyze powders and solids with its included single position sample holder. It also has a single element option for Al, Si, P, S, Cl, K, Ca, or Zr and can measure Zirconium or Phosphorus pretreatment.

The PortaSpec® XLE is operated by a PC Notebook Computer, complete with Windows®-based preinstalled Software.

Software

Powering Cianflone’s full line of Portable X-ray Spectrographic Analyzers is PortaSpec® PCS Software—a Windows®-based application that provides excellent records of prior analyses, improves productivity, and simplifies analysis. PortaSpec® PCS Software is designed for multiple industries including; tubing and bar stock, mining and minerals, petroleum, high and low-alloy steel, scrap metals, glass, synthetic and natural fibers, building materials, can, chemical research, alloy research, automotive, nuclear testing, and welding.

Configurations

Fixed Single Element (FSE)

When analysis of a single element is all that is required, the FSE configuration provides a value-engineered solution that is easy on the budget while maintaining the same precision as more expensive units.  While lacking the flexibility to be used on multiple elements, the fixed single element analyzer performs at the same high level of precision and provides accurate results targeted to single element analysis.

Included Items

  • Electric Water Coolant and Circulator
  • Vacuum Pump
  • Windows®-based Notebook Computer
  • PC Interface and Preinstalled Software
  • Software training and upgrades for up to a year are included with your PortaSpec® purchase.

Specifications

  • Bragg Angle Range 13 to 98 degrees; Two Theta
  • Analyzing Crystal Lithium Fluoride (200)
  • Element Range Ka 22-47 (Ti to Ag)
  • Element Range La 56-92 (Ba to U)
  • Collimators 20 mil Divergent (Source)
  • 10 mil Receiving (Exit)
  • X-ray Source X-Ray Tube, Tungsten Target, Beryllium Window
  • X-ray Tube Voltage 30 kV Constant Potential
  • X-ray Tube Voltage Regulation plus/minus 1% for plus/minus 10% line voltage variation
  • X-ray Tube Current 0 to 5 mA – Adjustable
  • Detector Tube Sealed Proportional
  • Detector Supply 0-2700 VDC Max. (Adjustable)
  • Digital Scaler and Timer Counting Range: 1 to 999,999
  • Timer Range: 1 to 990 seconds
  • Lamps X-Ray On
  • Supply Requirements 115 Volts AC,  60 Hz, 300 Volts
  • Optional 230 Volts, Single Phase, 50 Hz
  • Two-Position Sample Holder
  • Dimensions and Weight: Power Supply 18″ Long, 14″ Wide, 13″ High, 59 lbs.    Probe Head:  12″ Long, 3-1/2″ Wide, 9″ High, 14 lbs.
